1 Prerequisites

# This project requires ROS2 Humble. If not installed, refer to:
# wget http://fishros.com/install -O fishros && chmod +x ./fishros && ./fishros

sudo apt install libgflags-dev
sudo apt install libyaml-cpp-dev

# The following packages require ROS2 Humble on the host machine
sudo apt install ros-humble-joy
sudo apt install ros-humble-grid-map-msgs
sudo apt install ros-humble-grid-map-ros
sudo apt install ros-humble-rmw-cyclonedds-cpp

# Download onnxruntime
# Reference: https://github.com/microsoft/onnxruntime/releases/download/v1.23.2/onnxruntime-linux-x64-1.23.2.tgz

# 1. Extract the archive
tar -zxvf onnxruntime-linux-x64-1.23.2.tgz
# 2. Copy headers to system directory
sudo mkdir -p /usr/local/include/onnxruntime
sudo cp -r onnxruntime-linux-x64-1.23.2/include/* /usr/local/include/onnxruntime/

# 3. Copy libraries to system directory
sudo cp -r onnxruntime-linux-x64-1.23.2/lib/* /usr/local/lib/
sudo mkdir -p /usr/local/lib64
sudo cp -r onnxruntime-linux-x64-1.23.2/lib/* /usr/local/lib64/

# 4. Update dynamic library cache
sudo ldconfig

2 Quick Start

2.1 Launch the motion-control example node

  • Enter the project directory

cd x2_rl_deploy

  • Build the project

colcon build

  • Source the environment

source /opt/ros/humble/setup.bash
source install/local_setup.bash

  • Run the motion-control example

ros2 run x2_rl_deploy_controller x2_rl_deploy_controller

2.2 Launch the simulation node

  • Enter the project directory

cd x2_rl_deploy/x2_rl_deploy_mujoco

  • Source the environment

source /opt/ros/humble/setup.bash
source ../install/local_setup.bash

  • Run the simulation environment

cd bin
./start_sim.sh -s

Select 0: lx2501_3_t2d5 at the command-line prompt.

2.3 Launch the gamepad node

Before running the command below, connect your PS5 controller to the host machine with a USB-C cable.

  • Start the gamepad node

source /opt/ros/humble/setup.bash
ros2 run joy joy_node

Run the RL model example

After all three nodes (RL deployment example, simulation, and gamepad) are running, you can use the RL model example:

  1. Switch to position-control mode (optional)

  2. After adjusting the robot pose, press 🟥 on the PS5 controller to enter the RL deployment mode example.

  3. Press ⭕️ to enter damping mode when finished.

How to adjust the robot pose in simulation:

  1. [Recommended] Press Backspace to reset the robot’s position in MuJoCo.

  2. Double-click to select a target joint, then use Ctrl + left-click to rotate it.

  3. Double-click to select a target joint, then use Ctrl + right-click to drag it.

2.4 Button Mapping

❌ - PASSIVE_DEFAULT (zero-torque mode)
⭕️ - DAMPING_DEFAULT (damping mode)
🔺 - JOINT_DEFAULT   (position-control mode)
🟥 - RL_DEFAULT      (RL deployment mode example)

  1. Zero-torque mode is the default mode.

  2. Damping mode is the safe mode.

  3. It is recommended to switch to position-control mode before entering RL deployment mode example.

3 Directory Structure

x2_rl_deploy
├── aimdk_msgs/                     # Custom message package
│   ├── CMakeLists.txt
│   ├── interface/
│   └── package.xml
├── format.sh
├── rl_deploy_topology.png
├── README.md                        # This file
├── x2_rl_deploy_controller/
│   ├── CMakeLists.txt
│   ├── config/                      # Configuration directory
│   │   ├── motion_control.yaml      # Motion control config (initial pose and RL example settings)
│   │   └── rl_model/                # ONNX model file directory
│   ├── include/
│   │   └── x2_rl_deploy_controller/
│   ├── package.xml
│   └── src/                         # Source directory
│       ├── main.cc                  # Entry point
│       ├── motion_control_node.cc   # Motion control node
│       └── predictor/               # ONNX inference engine
└── x2_rl_deploy_mujoco/
    ├── bin/                         # Simulation executable directory
    ├── COLCON_IGNORE
    ├── configuration/               # MuJoCo configuration files
    ├── lib/
    └── version.json                 # Version info

4 Model Deployment

  • In the following, <model_name>.onnx refers to your model file.

  • Before running, copy your trained ONNX model file to x2_rl_deploy_controller/config/rl_model and update the path in x2_rl_deploy_controller/config/motion_control.yaml.

rl_config:
  policy:
    type: "onnx"
    device: "cpu"
    path: "x2_rl_deploy_controller/config/rl_model/<model_name>.onnx"

  • Adapt the code to your policy

# Customize the RlDefault() function as needed to adapt your policy
x2_rl_deploy_controller/src/motion_control_node.cc

5 Communication Protocol

5.1 Communication Topology

Communication topology

5.2 Joint State Subscription Topics

Joint

Publisher

Subscription

Topic name

Data type

Frequency (Hz)

Arm

hal_ethercat

mc

/aima/hal/joint/arm/state

aimdk_msgs/msg/JointStateArray

1000

Waist

hal_ethercat

mc

/aima/hal/joint/waist/state

aimdk_msgs/msg/JointStateArray

1000

Leg

hal_ethercat

mc

/aima/hal/joint/leg/state

aimdk_msgs/msg/JointStateArray

1000

Head

hal_ethercat

mc

/aima/hal/joint/head/state

aimdk_msgs/msg/JointStateArray

1000

5.3 IMU State Subscription Topics

Joint

Publisher

Subscription

Topic name

Data type

Frequency (Hz)

Chest

hal_imu

mc

/aima/hal/imu/chest/state

sensor_msgs/msg/Imu

500

Pelvis

hal_imu

mc

/aima/hal/imu/torso/state

sensor_msgs/msg/Imu

500

5.4 Control Command Publication Topics

Joint

Publisher

Subscription

Topic name

Data type

Frequency (Hz)

Arm

mc

hal_ethercat

/aima/hal/joint/arm/command

aimdk_msgs/msg/JointCommandArray

500

Waist

mc

hal_ethercat

/aima/hal/joint/waist/command

aimdk_msgs/msg/JointCommandArray

500

Leg

mc

hal_ethercat

/aima/hal/joint/leg/command

aimdk_msgs/msg/JointCommandArray

500

Head

mc

hal_ethercat

/aima/hal/joint/head/command

aimdk_msgs/msg/JointCommandArray

500
